Manufacturer,Stockist and Exporter of A105 Heavy Duty Blind Flange

A105 Heavy Duty Blind Flange, A105 Heavy Duty Blind Flange, A105 Heat Exchanger Flange, ANSI/ASME B16.47 Series B Blind Flange, a105 blind flange, A105 Marine Flange,A105 Heavy Duty Blind Flange,ANSI B16.47 Series A Blind Flange

A105 Heavy Duty Blind Flange is a specialized type of forged carbon steel flange designed to seal the end of pipelines or pressure vessels in high-stress industrial environments. Manufactured using ASTM A105 grade carbon steel, this flange offers superior strength and durability under high-pressure and high-temperature conditions. The "heavy duty" specification implies increased wall thickness and a robust design to handle more demanding applications compared to standard blind flanges.

As a manufacturer, stockist, and exporter, many global suppliers—including firms based in India and other industrial hubs—supply A105 Heavy Duty Blind Flanges for use across oil & gas, petrochemical, refinery, power generation, and offshore industries. These flanges are available in a wide range of sizes and pressure ratings (Class 150 to 2500), and are manufactured in accordance with international standards such as ASME B16.5 and B16.47.

A105 Heavy Duty Blind Flanges are especially valued in markets that demand both strength and reliability. They are forged for structural integrity and are capable of withstanding high mechanical stress. These flanges also provide excellent sealing performance, making them suitable for systems that must be closed off securely during maintenance or isolation procedures.

These flanges are widely exported to several international markets including Oman, Qatar, Saudi Arabia, UAE, Kuwait, Spain, Germany, the USA, Canada, and various countries across Africa. Exporters maintain ready stocks to ensure timely delivery and often customize coatings such as galvanizing, painting, or PTFE for specific environments, especially in corrosive or marine settings.

Specification of A105 Heavy Duty Blind Flange

Specification	Details
Material Grade	ASTM A105 (Carbon Steel)
Flange Type	Blind Flange
Wall Type	Heavy Wall (thicker body for high-pressure applications)
Manufacturing Process	Forged
Pressure Ratings	ANSI Class 150, 300, 600, 900, 1500, 2500
Size Range	½” to 60” (DN15 to DN1500)
Standards	ASME B16.5, ASME B16.47, API 6A
Face Type	RF (Raised Face), FF (Flat Face), RTJ (Ring Type Joint)
Surface Finish	Serrated, Smooth, Stock
Coating/Finish	Anti-rust oil, Black Paint, Galvanized, Epoxy, or Custom
Temperature Range	-29°C to 425°C (-20°F to 800°F)
Applications	Oil & Gas, Petrochemicals, Power Plants, Marine, Water Treatment
Testing & Certification	EN 10204 3.1 / 3.2, NACE MR0175, ISO 9001, PED compliant

The mechanical properties of A105 Heavy Duty Blind Flanges include a minimum tensile strength of 485 MPa and a yield strength of 250 MPa, with high elongation and hardness limits suited for heavy industrial use. Many of these flanges are tested according to stringent quality control standards and come with certifications such as EN 10204 3.1/3.2, ensuring compliance with project specifications globally.

A105 Heavy Duty Blind Flanges play a crucial role in high-pressure piping systems and are trusted for their durability and performance. Their wide availability, customization options, and global compliance make them a preferred choice for engineers and procurement teams worldwide, particularly in mission-critical operations where safety and reliability are paramount.

A105 Heavy Duty Blind Flange Chemical Properties

Element	Composition (%)
Carbon (C)	≤ 0.35
Manganese (Mn)	0.60 – 1.05
Phosphorus (P)	≤ 0.035
Sulfur (S)	≤ 0.040
Silicon (Si)	0.10 – 0.35
Copper (Cu)	≤ 0.40 (if specified)
Nickel (Ni)	≤ 0.40 (if specified)
Chromium (Cr)	≤ 0.30 (if specified)
Molybdenum (Mo)	≤ 0.12 (if specified)
Vanadium (V)	≤ 0.08 (if specified)

A105 Heavy Duty Blind Flange Mechanical Properties

Mechanical Property	Value
Tensile Strength (min)	485 MPa (70 ksi)
Yield Strength (min)	250 MPa (36 ksi)
Elongation (min)	22% in 50 mm (2 inches)
Reduction of Area	30% (typical)
Hardness (max)	187 HBW (Brinell) or 91 HRB (Rockwell B)
Impact Testing	Not mandatory unless specified
Service Temperature Range	-29°C to 425°C (-20°F to 800°F)

Features of A105 Heavy Duty Blind Flange

Healthy, non-toxic, and stain-free
High temperature and pressure resistance
Hot welding connection
Leak prevention
Excellent heat insulation
Lightweight and easy to transport
Smooth inner wall for reduced pressure loss
Low noise
Suitable for exposed or hidden installation
Chemical corrosion resistance

Available Types Of A105 Heavy Duty Blind Flange

A105 Pressure Vessel Flange	Forged A105 Blind Flange
A105 Heavy Duty Blind Flange	A105 RF Blind Flange
CS HEAVY BLRF FLANGE	ANSI B16.47 Series A Blind Flange
ANSI B16.47 Series B Blind Flange	MSS SP-44 A105 Blind Flange
A105 Schedule 160 Blind Flange	ANSI/ASME B16.5 Blind Flange
ANSI/ASME B16.47 Series A(MSS SP44) Blind Flanges	ANSI/ASME B16.47 Series B Blind Flange
carbon steel slip on flanges	Custom A105 Blind Flange
A105 Forged Oversized Flange	A105 XXS Blind Flange

Applications Industry

Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry

Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
