Manufacturer,Stockist and Exporter of A105 High Thickness Blind Flange

A105 High Thickness Blind Flange, A105 High Thickness Blind Flange, A105 Heat Exchanger Flange, ANSI/ASME B16.47 Series B Blind Flange, a105 blind flange, A105 Marine Flange,A105 High Thickness Blind Flange,ANSI B16.47 Series A Blind Flange

The A105 High Thickness Blind Flange is a specialized component designed for high-pressure and high-stress applications in industrial piping systems. Made from ASTM A105 carbon steel, this type of blind flange is characterized by its increased thickness, providing enhanced strength and durability where standard flanges may not suffice. It is used to seal off the ends of pipelines, valves, or equipment nozzles, making it ideal for systems that require isolation, pressure testing, or future expansion.

Raj Bhoomi Engineers is a reputable manufacturer, stockist, and exporter of A105 High Thickness Blind Flanges, catering to a wide range of industries including oil and gas, petrochemicals, power generation, marine, and infrastructure. With advanced in-house manufacturing capabilities and a strict quality assurance process, the company ensures that each flange meets international standards such as ASME, ANSI, and ASTM. These flanges are tested for pressure integrity, dimensional accuracy, and surface finish to guarantee top performance in critical environments.

The company has built a strong presence in the Middle East, supplying flanges to countries like Oman, Qatar, Saudi Arabia, UAE, and Kuwait. These regions demand robust and reliable components due to the extreme conditions and high operational pressures in oilfields, refineries, and energy facilities. The A105 High Thickness Blind Flange offered by Raj Bhoomi Engineers is engineered to handle these challenges, offering superior resistance to stress and corrosion.

Raj Bhoomi Engineers also exports to leading industrial nations, including Spain, Germany, the USA, and Canada, where engineering precision and compliance with global standards are critical. Their ability to deliver custom flange solutions, complete with material certifications and technical documentation, has made them a preferred supplier among international EPC contractors and equipment manufacturers.

Specification of A105 High Thickness Blind Flange

Parameter	Specification
Product Name	A105 High Thickness Blind Flange
Material Grade	ASTM A105 (Carbon Steel)
Flange Type	Blind Flange
Thickness	Higher than standard ASME B16.5/B16.47 thickness (custom as per requirement)
Size Range	1/2" to 72" (larger sizes available on request)
Pressure Class	Class 150, 300, 600, 900, 1500, 2500
Standards	ASME B16.5, ASME B16.47 (Series A & B), ANSI, ASTM
Face Type	Raised Face (RF), Flat Face (FF), Ring Type Joint (RTJ)
Surface Finish	Stock Finish (125–250 AARH) or as per client specifications
Dimensions Tolerance	As per ASME/ANSI standards
Corrosion Protection	Black paint, anti-rust oil, or galvanization (on request)
Testing & Inspection	Hydrostatic Test, Ultrasonic Test, MPI, PMI, as required by client
Documentation	EN 10204 3.1 / 3.2 certificates, compliance reports, and test results
Applications	High-pressure pipelines, refineries, offshore rigs, power plants, petrochemical
Manufacturer	Raj Bhoomi Engineers
Export Regions	Oman, Qatar, Saudi Arabia, UAE, Kuwait, Spain, Germany, USA, Canada, Africa, etc.

In addition to developed markets, the company serves various regions across Africa and other parts of the world, supporting infrastructure development and industrial growth with timely delivery and dependable products. With a wide inventory and a dedicated export division, Raj Bhoomi Engineers ensures fast turnaround times and comprehensive support for every project, regardless of location or scale.

By offering high-performance A105 High Thickness Blind Flanges, Raj Bhoomi Engineers continues to set benchmarks in quality, reliability, and service. Their expertise in flange manufacturing and global distribution makes them a trusted name in the piping and pressure equipment industry worldwide.

A105 High Thickness Blind Flange Chemical Properties

Element	Composition (%)
Carbon (C)	≤ 0.35
Manganese (Mn)	0.60 – 1.05
Phosphorus (P)	≤ 0.035
Sulfur (S)	≤ 0.040
Silicon (Si)	0.10 – 0.35
Copper (Cu)	≤ 0.40 (if specified)
Nickel (Ni)	≤ 0.40 (if specified)
Chromium (Cr)	≤ 0.30 (if specified)
Molybdenum (Mo)	≤ 0.12 (if specified)
Vanadium (V)	≤ 0.08 (if specified)

A105 High Thickness Blind Flange Mechanical Properties

Property	Value / Specification
Tensile Strength	≥ 485 MPa (70,000 psi)
Yield Strength	≥ 250 MPa (36,000 psi)
Elongation	≥ 22% (in 50 mm or 2 inches)
Reduction of Area	≥ 30%
Hardness	≤ 187 HB (Brinell Hardness)
Impact Test (Charpy V)	Optional – as per client requirement
Heat Treatment	Forged, Normalized, or Normalized & Tempered
Service Temperature	-29°C to 425°C (-20°F to 800°F)
Testing Standards	As per ASME/ASTM specifications

Features of A105 High Thickness Blind Flange

Healthy, non-toxic, and stain-free
High temperature and pressure resistance
Hot welding connection
Leak prevention
Excellent heat insulation
Lightweight and easy to transport
Smooth inner wall for reduced pressure loss
Low noise
Suitable for exposed or hidden installation
Chemical corrosion resistance

Available Types Of A105 High Thickness Blind Flange

A105 Pressure Vessel Flange	Forged A105 Blind Flange
A105 Flange RTJ	A105 RF Blind Flange
CS HEAVY BLRF FLANGE	ANSI B16.47 Series A Blind Flange
ANSI B16.47 Series B Blind Flange	MSS SP-44 A105 Blind Flange
A105 Schedule 160 Blind Flange	ANSI/ASME B16.5 Blind Flange
ANSI/ASME B16.47 Series A(MSS SP44) Blind Flanges	ANSI/ASME B16.47 Series B Blind Flange
carbon steel slip on flanges	Custom A105 Blind Flange
A105 Forged Oversized Flange	A105 XXS Blind Flange

Applications Industry

Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry

Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
