Manufacturer,Stockist and Exporter of CS Heavy BLRF Flange

CS Heavy BLRF Flange, CS Heavy BLRF Flange, A105 Heat Exchanger Flange, ANSI/ASME B16.47 Series B Blind Flange, a105 blind flange, A105 Marine Flange,CS Heavy BLRF Flange,ANSI B16.47 Series A Blind Flange

Raj Bhoomi Engineers is a leading manufacturer, stockist, and exporter of CS Heavy BLRF Flanges (Carbon Steel Heavy Blind Raised Face Flanges), catering to a diverse clientele across various industries worldwide. Specializing in high-quality carbon steel flanges, the company ensures that each product meets stringent international standards, making them suitable for a wide range of applications.

The CS Heavy BLRF Flanges produced by Raj Bhoomi Engineers are designed to provide secure and leak-proof connections in piping systems. These flanges are particularly useful in situations where a temporary seal is required, such as during maintenance or system testing. The raised face design enhances the sealing surface, ensuring a tight fit and preventing leaks under high-pressure conditions.

Raj Bhoomi Engineers' commitment to quality is evident in their adherence to stringent manufacturing processes and quality control measures. Each CS Heavy BLRF flange undergoes rigorous testing to meet industry standards, ensuring reliability and durability in demanding environments. The company's expertise in producing flanges with precise dimensions and surface finishes contributes to the overall performance and longevity of the piping systems they are part of.

With a global presence, Raj Bhoomi Engineers exports CS Heavy BLRF flanges to various countries, including Oman, Qatar, Saudi Arabia, UAE, Kuwait, Spain, Germany, the USA, Canada, and several regions in Africa. Their extensive export network underscores their capability to meet international demand and deliver products that comply with global standards.

Specification of CS Heavy BLRF Flange

Specification	Details
Material	Carbon Steel (CS), typically ASTM A105 / A105N
Type	Blind Raised Face (BLRF), Heavy-Duty
Pressure Class	Class 150, 300, 600, 900, 1500, 2500 (as per ASME B16.5 / B16.47)
Size Range	½" to 48" (DN15 to DN1200)
Design Standard	ASME B16.5 / ANSI B16.47 / DIN / EN / BS / ISO
Face Type	Raised Face (RF), also available in Flat Face (FF) or Ring Type Joint (RTJ)
Wall Thickness	Extra-thick / Schedule 80, 120, 160, XXS (as per customer requirement)
Connection Type	Blind – No bore, used to seal pipe ends or openings
Surface Finish	Serrated / Smooth finish on raised face
Coating	Anti-rust oil, black paint, zinc coated, or custom finishes
Application Industries	Oil & Gas, Petrochemicals, Refineries, Marine, Power Plants, Construction

The company's strategic location in India allows for efficient manufacturing and distribution, enabling timely delivery to international markets. Raj Bhoomi Engineers' focus on customer satisfaction, coupled with their technical expertise, positions them as a reliable partner for industries seeking high-quality CS Heavy BLRF flanges for their piping systems.

Raj Bhoomi Engineers stands out as a trusted manufacturer, stockist, and exporter of CS Heavy BLRF flanges, offering products that meet international standards and cater to a diverse clientele across various industries worldwide.

CS Heavy BLRF Flange Chemical Properties

Element	Composition (%)	Remarks
Carbon (C)	≤ 0.35	Increases hardness and strength
Manganese (Mn)	0.60 – 1.05	Improves tensile strength and toughness
Phosphorus (P)	≤ 0.035	Kept low to avoid embrittlement
Sulfur (S)	≤ 0.040	Excess can lead to brittleness
Silicon (Si)	0.10 – 0.35	Enhances strength and corrosion resistance
Copper (Cu)*	≤ 0.40	Optional — improves corrosion resistance
Nickel (Ni)*	≤ 0.40	Optional — improves toughness
Chromium (Cr)*	≤ 0.30	Optional — increases hardness and strength
Molybdenum (Mo)*	≤ 0.12	Optional — enhances high-temperature strength
Vanadium (V)*	≤ 0.08	Optional — grain refinement

CS Heavy BLRF Flange Mechanical Properties

Property	Value	Unit	Remarks
Tensile Strength	≥ 485	MPa (≥ 70 ksi)	Minimum value per ASTM A105/A105N
Yield Strength	≥ 250	MPa (≥ 36 ksi)	0.2% offset method
Elongation	≥ 22	%	Over 50 mm (2 inch) gauge length
Reduction of Area	≥ 30	%	Indicates material ductility
Hardness (Brinell)	≤ 187	HB	Typically softer for better machinability
Impact Strength (Charpy)	> 27 (at -20°C, if normalized)	Joules	Applicable when "N" (Normalized) is specified

Features of CS Heavy BLRF Flange

Healthy, non-toxic, and stain-free
High temperature and pressure resistance
Hot welding connection
Leak prevention
Excellent heat insulation
Lightweight and easy to transport
Smooth inner wall for reduced pressure loss
Low noise
Suitable for exposed or hidden installation
Chemical corrosion resistance

Available Types Of CS Heavy BLRF Flange

A105 Pressure Vessel Flange	Forged A105 Blind Flange
A105 Flange RTJ	A105 RF Blind Flange
CS Heavy BLRF Flange	ANSI B16.47 Series A Blind Flange
ANSI B16.47 Series B Blind Flange	MSS SP-44 A105 Blind Flange
A105 Schedule 160 Blind Flange	ANSI/ASME B16.5 Blind Flange
ANSI/ASME B16.47 Series A(MSS SP44) Blind Flanges	ANSI/ASME B16.47 Series B Blind Flange
carbon steel slip on flanges	Custom A105 Blind Flange
A105 Forged Oversized Flange	A105 XXS Blind Flange

Applications Industry

Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry

Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
